KTHF-IC Carbon Black Dispersion Tester

Used for testing the dispersion degree of colorants and carbon black in polyolefin pipes, fittings, and compounds; through measuring the size, morphology, and distribution of carbon black agglomerates.

Classification :

Plastic Pipe Testing Machine

WhatsApp : ‪+8613405319966

E-mail : sales1@jianketest.com

PRODUCT DETAILS

Standards Compliance:

GB/T 18251 Determination of Dispersion Degree of Pigments or Carbon Black in Polyolefin Pipes, Fittings, and Compounds;

ISO/DIS 18553;

Product Features:

Professional image-based detection with high precision, and the measurement accuracy is traceable;

Measured parameters cover rich information on the size (equivalent diameter, length and short diameter, area, perimeter, etc.) and morphology (roundness, rectangularity, aspect ratio, etc.) of carbon black agglomerates;

Professional processing program: Ensures accurate results of carbon black components, and automatically completes the process from image acquisition to result output;

Data analysis and report system: Based on the standard carbon black dispersion statistical report template, it fully meets users' personalized needs for statistical methods and report formats;

Compatible with various acquisition devices (cameras or digital cameras) and matches different computers;

Product Parameters:

Serial Number	Item	Parameters
1	Detection range	1μm～1cm
2	Imaging resolution	2592×1944
3	Scanning system	625 lines, 50 fields/second
4	Synchronization system	Internal synchronization/vertical sync lock
5	Horizontal resolution	600 lines
6	Sample window aperture	4mm
7	Testing area	1.7×1.25mm
8	Optical magnification	100x
9	Light source irradiation angle	30°
10	Image size	320×240 pixels
11	Power supply voltage	220V±10%, 50Hz (must be reliably grounded)

Product Configuration (Subject to final order):

Serial Number	Name	Origin	Quantity
1	Computer	Brand	1 set
2	Optical microscope		1 set
3	Camera		1 piece
4	Intelligent programming software	Jianke	1 set
5	Equipment files	Instruction manual, certificate of conformity, packing list	1 set

APPLICATION FIELD

Aerospace

Automobile Manufacturing

Mechanical Manufacturing

Electronic Components

Textile Industry

Wires and Cables

CERTIFICATES

Computer Software Copyright Registration Certificate Electro-hydraulic Servo Universal Testing Machine Measurement and Control System V1.0

Computer Software Copyright Registration Certificate Electronic Universal Testing Machine Embedded System V1.0

Computer Software Copyright Registration Certificate Constant Temperature and Humidity System Control Software V1.0

Computer Software Copyright Registration Certificate for Interactive Universal Testing Machine Measurement and Control System V1.0

Computer software copyright registration certificate Pressure testing machine embedded system V1.0

Invention Patent Certificate Building Material Density Testing Machine

Utility Model Patent Certificate A deformation measuring device

Utility Model Patent Certificate A Glass Optical Inspection Equipment
