YAW-300G Automatic Manhole Cover Pressure Testing Machine

The microcomputer-controlled constant stress flue pressure testing machine is mainly used for vertical load-bearing capacity testing and research of exhaust duct products such as residential kitchen PC, bathroom PW, bathroom PWW, S-type exhaust ducts, X-type exhaust ducts, and shared exhaust ducts, which are made of wire mesh cement, glass fiber mesh, reinforced materials and other cement prefabrications, high-strength magnesium oxide fireproof boards, etc.

Classification :

Hydraulic pressure testing machine

WhatsApp : ‪+8613405319966

E-mail : sales1@jianketest.com

PRODUCT DETAILS

General Function Description:

Compliance Standards:

JG/T 194: Residential Kitchen and Bathroom Smoke (Gas) Exhaust Duct Products
JGJ/T 455: Technical Standard for Residential Exhaust Duct System Engineering
CECS 390: Technical Specification for Application of Residential Exhaust Duct Systems
GB 50096: Code for Design of Residential Buildings
GB/T 30812: Glass Fiber Reinforced Plastic Flue for Coal-Fired Power Plants
JC/T 854: Glass Fiber Reinforced Cement Exhaust Ducts
GB/T 15231: Test Methods for Properties of Glass Fiber Reinforced Cement
GB 50368: Residential Building Code

Product Features:

Ultra-long stroke electric screw lifting makes experiments more convenient and on-site entry easier.
Explosion-proof protection device makes the test safer.
Ultra-low test bench makes it easier to place test pieces.
Branded computer significantly enhances the laboratory image, with a unique SmartTest operating interface for a smooth user experience.
The hydraulic system is equipped with a three-phase asynchronous motor and a high radial piston pump, featuring high efficiency and stability.

Product Parameters:

Parameter	Specification
Maximum test force	300kN
Accuracy class	Class 1
Test force measurement range	1%-100%FS
Test force resolution	1/200000 of the maximum force, with constant resolution throughout the range
Maximum cylinder stroke	150mm
Effective compression space	100-1200mm
Piston displacement speed	0-50mm/min
Tensile stroke	250mm
Power	1.1KW
Testing machine dimensions (for testing)	900mm×620mm×3400mm
Testing machine dimensions (for transportation and entry)	900mm×620mm×2200mm
Power supply	Three-phase four-wire (neutral line) AC 380V±10% 50Hz; 1.5kW
Main machine weight	1400kg

Product Configuration (Subject to final order):

Serial Number	Name	Description	Quantity
1	Testing machine main unit	-	1 unit
2	Servo oil source	Console type	1 unit
3	Servo hydraulic system (servo motor + oil pump valve group)	-	1 set
4	Commercial computer	-	1 unit
5	SmartTest operating system	-	1 set
6	30T load sensor	-	1 set
7	Mouse and keyboard	-	1 set
8	Instruction manual	-	1 copy
